17.05 L

pushing the envelope

mATX

unique in this size


C4-MATX v1
The C4-MATX case was developed with focus on strong cooling and high-end hardware compatibility - while also accommodating even larger components than the C4-SFXv2.

This case uses a heavly optimized classic hardware layout. The list of features is long – 280mm radiator support, big air cooler up to 157mm in height, indirect GPU cooling, ITX, deep ITX, DTX, mATX, 4.4 slot over sized length GPU, SFX & SFX-L Power Supply support, s.o. All this is packed in an elegant enclosure with ~17 L made by Lian Li. The main difference compared to the C4-SFX is its support for mATX motherboards, along with compatibility for even larger GPUs and CPU heatsinks.

This case is the perfect match for SFF (Small Form Factor) enthusiasts, developers who require a case with a smaller footprint due to limited desk space and gamers who want a high-end PC experience in their living room.

The case was developed in cooperation with the community from the following forums:





How It Works
The case allows for tower heatsinks an height of 157mm like the Thermalright PA120 SE. The motherboard tray can be adjusted to support both mATX and ITX motherboards. Depending on the chosen configuration, the power supply can be installed in three different positions. With the radiator bracket it is possible to install 120, 140, 240 or 280mm radiators with 25mm thick fans for the best cooling results. You can install 4.4 slot GPUs with a length of up to 360mm. Two 120 or 140mm fan mount points at the top of the case allows for feeding the GPU with fresh air.

Two 2.5” HDDs or SSDs can be mounted at the front. The drives will be mounted with rubber spacers to reduce vibration and noise.

The case does come with a air-flow-tunnel and a CPU heatsink heat shield. This will shield tower heatsink from exhaust heat from double-blow through cards like RTX 5080/5090 Founders Edition. This will result in much better CPU temps.



Partner
The all-aluminum body will be manufactured again by Lian Li in Taiwan per their highest quality standards. A commitment to quality lies at the core of our business philosophy.






Where to buy
For the C4-MATXv1 we plan to work together with the following shops:



Europe customers

UK, USA, Canada, NewZealand, Norway customers


All countries

Japan customers
